5.
If a string corresponding to the search criteria is found in the UML/SD Viewer,
the string is highlighted and the following message is displayed: Runtime
Tracing has finished searching the document.
6. Click
OK.
Search Options
·
Forward and Backward specifies the direction of the search.
·
The Search into option allows you to specify type of object in which you expect
to find the search string.
·
The Find dialog box accepts either UNIX regular expressions or DOS-like
wildcards ('?' or '*'). Select either wildcard or reg. exp. in the
Find
dialog box to
select the corresponding mode.
UML/SD Viewer Toolbar
The UML/SD Viewer toolbar provides shortcut buttons to commands related to
viewing graphical test reports and UML sequence diagrams.
UML/SD Viewer commands are only available when a UML sequence diagram is
open.
·
The Filter button allows you to define a sequence diagram filter.
·
The Trigger button sets sequence diagram triggers.
The following buttons are only available when using the Step-by-Step mode.
·
The Step button moves the UML/SD Viewer to the next selected event.
·
The Select button allows you to select the type of event to trace.
·
The Continue button draws everything to the end of the trace diagram.
·
The Restart button restarts Step-by Step mode.
·
The Pause button pauses the On-the-Fly display mode. The application
continues to run.
The TDF file selector is only available when using the Split TDF File feature.
·
Click the button to select a .tdf dynamic trace file from the list.
·
Click the and buttons to select the previous or next file in the list.
To hide or show a toolbar:
1.
Right-click an empty area within the toolbar.
2.
Select and clear those toolbars you want to display or hide.
3. Click
OK.
