Boolean Operators

Graphical User Interface

Instance child of: Specifies a note attached to an instance of the specified class

Note on message named: Considers a note attached to a specified message

With style named: Considers a note with the specified style attributes

Synchronization Criteria

All: Considers all synchronization events

Name: Specifies a synchronization name

Action Criteria

All: Considers all actions

Name: Specifies an action name

From Instance: Considers an action performed by the specified object

From World: Considers all actions performed by the World instance

Instance child of: Specifies an action performed by an instance of the specified
class

With style named: Considers an action with the specified style attributes

Loop Criteria

All: Considers all loops

Name: Specifies a loop name

Boolean Operators

All Except expresses a NOT operation on the criteria

Match All performs an AND operation on the series of criteria

Match Any performs an OR operation on the series of criteria

Finding Text in a UML Sequence Diagram

The UML/SD Viewer has an extensive search facility that allows users to locate
specific UML sequence diagram elements by searching for a text string.

To search for a text string inside the UML/SD Viewer:

Click inside a UML/SD Viewer window to activate it.

2. From

the

Edit menu, select Find menu item. The Find dialog box opens.

Type your search criteria in the Find dialog box.

4. Click

the

Find Next button.
