Message Criteria
Test RealTime - User Guide
2.
Select the type of UML element you want to define for the event and select
Activate. Several types of elements can be activated for a single filter or trigger
event.
3. Click
More or Fewer to add or remove line to the event criteria.
4.
From the drop-down criteria box, select a criteria for the filter, and an argument.
5.
Arguments must reflect an exact match for the criteria. Pay particular attention
when referring to labels that appear in the sequence diagram since they may be
truncated.
6.
You can use wildcards (*) or regular expressions by selecting the corresponding
option.
7. Click
the button to enable or disable case sensitivity in the criteria.
8.
You can add or remove a criteria by clicking the More or Fewer buttons.
9. Click
Ok.
Message Criteria
·
Name: Specifies a message name as the filter criteria.
·
Internal message: Considers all messages other than constructor calls coming
from any internal source, as opposed to those messages coming from the World
instance.
·
From Instance: Considers all messages other than constructor calls prior to the
first message sent from the specified object
·
To Instance: Considers out all messages other than constructor calls if any
message is sent to the specified object
·
From World: Considers all messages received from the World instance
·
To World: Considers all messages sent to the World instance
Instance Criteria
·
Name: Specifies an instance name as the filter criteria
·
Instance child of: Specifies a child instance of the specified class.
Note Criteria
·
All: Considers all notes
·
Name: Specifies a note name
·
All message notes: Considers any note attached to a message
·
All instance notes: Considers any note attached to an instance
