TDP compilation fails

Test RealTime - User Guide

Compilation fails

Ensure that the selected Target Deployment Port matches your
compiler; there may be several Target Deployment Ports for
one OS, each of which targets a different compiler. If you are
unsure, you can check the full name of a Target Deployment
Port by opening any of the .ini files located in the Target
Deployment Port directory.

When using the -I- linker option, the TDP fails to compile. This
is because the following line is added to the instrumented file:

#include "<path to target
directory>/TP.h"

where TP.h includes other files using the #include syntax, such
as:

#include "clock.h"

where clock.h is in the same directory as "TP.h". If you use the -
I- flag, the compiler no longer searches the same directory as
the current file (TP.h) and therefore cannot find clock.h. If you
cannot remove the -I- flag, you must add a -I flag for the
compiler to find the include files required by the TDP.

Compiler reports that
options.h is missing

Ensure that you have correctly prepared the options.h file, and
that this file is located in a directory that is searched by your
compiler (this is usually specified with -I or /I option on the
compiler command line).

Compiler reports that
TP.h file is missing

If you are compiling on a target different from the host where
the generated file has been produced, double-check the above
specific requirements to compilation on a different target.
If the test compiler and C/C++ compiler are executed on the
same machine, ensure you have not used the -NOPATH option
on the test compiler command line, and that the ATLTGT
environment variable was correctly set while the test script
compiler was executed.

Linkage fails because of
undefined references

Ensure you have successfully compiled the Target Deployment
Port library object, and have included it in your linked files
Ensure you have correctly configured the products.h options
file.
If you are using a test feature, ensure that you are linking both
source under test and additional files. You may also want to
add some stubs in your .ptu or .otd test script.
Ensure the options set in options.h (if required) are coherent
with the options set in products.h.

Errors are reported
through

#error

directives

You may have selected a combination of options in products.h
which is incompatible. The error messages help you to locate
the inconsistencies.
