Rational Robot Tutorial: SQL statement

SQL statement

Setting Script Generation Options

6-15

Example of the Verify Playback Check Boxes

Suppose you want the script to execute the following SQL statement:

INSERT INTO mytable VALUES ("value1", "value2")

Depending on your

Verify playback row counts

and

Verify playback return codes

selections, Robot generates the SQL statement in one of the following ways:

Because one SQL statement can return multiple error messages (for example, as a
result of stored procedure execution),

EXPECT_ERROR

is an array. During

playback, if an error code is returned that is not one of the values specified in the
array, TestManager generates an error.

Check box
selected

VU command and meaning

Neither

sqlexec ["x001"] "INSERT INTO mytable VALUES
('value1', 'value2')";

During recording, Robot does not report the data it collects from the

execution of the SQL statement. During playback, TestManager

assumes that any non-zero return code is an error. It pays no attention

to the number of affected rows.

Verify playback

return codes

sqlexec ["x001"] EXPECT_ERROR {-212}, "INSERT
INTO mytable VALUES ('value1', 'value2')";

Robot records that the error code -212 was returned from the SQL

statement. During playback, TestManager expects the SQL statement

to return the error code -212. If the SQL statement returns a different

code during playback, the Test Log window notes the discrepancy.

Verify playback

row counts

sqlexec ["x001"] EXPECT_ROWS 1, "INSERT INTO
mytable VALUES ('value1', 'value2')";

Robot records that one row was affected by the SQL statement.

During playback, TestManager expects the SQL statement to affect

one row. If the SQL statement returns a different count during

playback, the Test Log window notes the discrepancy.

Both

sqlexec ["x001"] EXPECT_ERROR {-212},
EXPECT_ROWS 0, "INSERT INTO mytable VALUES
('value1', 'value2');

Robot records that the SQL statement returned the error code -212,

and that no rows were affected. During playback, TestManager

expects that the SQL statement will return error -212 and that no

rows will be affected. If the SQL statement returns different results

during playback, the Test Log window notes the discrepancy.
