Next, use the Add and Remove buttons to build a list of interface files. The
Interface Files List must contain files that define the communication routines of
your application.
Click Next to continue.
3. Specify
the
include
directories for your application.
Use the Add and Remove buttons to build a list of
include
directories. These are
all the directories that contain files that are
included
by your application's
source code. Use the Up and Down buttons to indicate the order in which they
are searched.
Click Next to continue. If you chose to create a new .pts test script, this brings
you straight to step 6.
4.
Create a set of Virtual Testers.
See Configuring Virtual Testers for information about this page. If necessary,
click the Configure Settings button to access the Configuration Settings for the
selected Virtual Tester node.
Click Next to continue.
5.
Deploy the Virtual Testers onto your target hosts.
See Deploying Virtual Testers for information about this page.
Click Next to continue.
6.
Perform a quick review of the options in the Summary Page, and use the <Back
button if necessary to make any changes.
·
Test Script File: indicates the name of the .pts test script
·
Interface Files: lists the interface files defining the communication routines of
your application.
·
Included Directories: lists the directories containing files
inc uded
by your
application.
l
·
Virtual Testers: lists the Virtual Tester that are to be deployed by the System
Testing node.
7. Click
the
Finish button to launch the generation of the System Testing node
with the corresponding Virtual Testers.
The wizard creates a test node with the associated test scripts. The test node appears
in the Project Explorer.
If you chose to create a new .pts test script, you can now write your System Testing
test script in the Text Editor and then configure and deploy your Virtual Testers.
