Flushing the Trace Buffer through a User Directive

Test RealTime - User Guide
Flushing the Trace Buffer through a User Directive
It can be useful to flush the buffer before entering a time-critical part of the
application-under-trace. You can do this by adding the _ATT_FLUSH_ITEMS user
directive to the source-under-trace.
Note See Runtime Tracing pragma directives in the Reference Manual to
control Target Deployment Port buffering from within the source code.
Splitting Trace Files
During execution, Runtime Tracing generates a .tdf dynamic file. When a large
application is instrumented, the size of the .tdf file can impact performance of
UML/SD Viewer.
Splitting trace files allows you to split the .tdf trace file into smaller files, resulting in
faster display of the UML Sequence Diagram and to optimize memory usage.
However, split trace files cannot be used simultaneously with On-the-Fly tracing.
When displaying split .tdf files, Runtime Tracing adds Synchronization elements to
the UML sequence diagram to ensure that all instance lifelines are synchronized.
To set Split Trace mode:
1. In
the
Project Explorer, select the highest level node from which you want to
activate split trace mode.
2. Click
the
Open Settings... button.
3. Select
Runtime Analysis and the Runtime Tracing settings.
Select Trace Control.
Set the Size (Kb) of each split .tdf. The default size is 5000 Kb.
Specify a File Name Prefix for the split .tdf filenames. The prefix is followed by
a 4-digit number that identifies each file.
4. Click
OK.
Note The total size of split .tdf files is slightly larger than the size of a single
.tdf file, because each file contains additional context information.
